DPB-250C Flat Plate Auto Blister Packaging Machine
Home / Pharmaceutical Products / Pharmaceutical Machinery / Blister Packaging Machine / DPP-150B-I Flat Plate Blister Packing Machine
DPP-150B-I Flat Plate Blister Packing Machine
It is the latest scientific products for pharmaceutical factory and health care factory as well as foodstuff process factory. It is adopted with micro-computer PLC Human interface (option) to operate, frequency converter, high automation, easy operation, advanced technology, full function, long durability, in accordance with GMP requirement, it is the ideal packaging equipment with high popularity. The products have been passed the Provincial Science and Technology Appraisal.
Product INTRODUCTION
Features
1.The main transmission is adopted with swinging pin gear reducer. With Long life, lower Noise and stable running.
2.Plate structure, adjustable stroke, it's suitable for different size packaging, also suitable for such as circular, ellipse, square, triangle, or irregular shape.
3.It can equipped with cursor trace registration, good looking sealing. (Option)
4.It can be equipped with optical fiber or photography detection device according to the customers'requirements. With inductive self-checking mechanism, it can eliminate by itself the waste plate with lack of particle, The unqualified rate reaches 100%.
Main Technical Parameters
Cutting Frequency(Times/min) | AL/AL 6-30,Al/plastic,paper/plastic6-35 |
Max.Forming area and depth(mm) | Al-Al 140*110*9 Al-plastic 140*110*14 |
Stroke(mm) | 40-120 can be manufactured as user's requirements |
Standard Plate(mm) | 80*57 can be manufactured as user's requirements |
Air Pressure(Mpa) | 0.4-0.6 |
Air supply | ≥0.2 m³/min |
Total Power | 380V/220V 50Hz 3.6kw |
Main Motor Power(kw) | 1.1 |
Forming Aluminum(mm) | 0.085-0.1*140 |
PVC Hard Pieces(mm) | 0.15-0.5*140 |
PTP Aluminum Foil(mm) | 50-100g*140 |
Dialysis Paper(mm) | 50-100g*140 |
Mould Cooling | tap water or recycling water |
Overall Dimensions(mm) | 2300*560*1410(L*W*H) |
Weight(kg) | 600 |
Wecaps Blister Packaging Machine
Professional and Complete Service SolutionsWecaps offers a wide array of products tailored to meet the specific needs of the food, medicine, and related industries. Our range includes cutting-edge machines like automatic capsule fillers, blister packagers, cartoners, tablet presses, counters, granulators, coaters, and ovens.These machines are equipped with state-of-the-art technology to ensure top-notch performance, simplifying your production processes and effortlessly adjusting to your changing needs.
Global Compliance and CertificationsAt Wecaps, we rigorously comply with regulatory standards in your chosen export destinations.Our machines proudly carry the esteemed CE certification from the European Union, ensuring strict adherence to the highest safety and quality benchmarks. Our packaging equipment production base spans over 12,000 square meters of modern industrial workshop, adhering to stringent SGS and ISO 9001:2015 quality certification management systems.
Delivery & Installation & Commissioning & After-SalesWecaps offers efficient logistics solutions to ensure secure and prompt delivery worldwide.Additionally, our comprehensive after-sales support ensures swift dispatch of highly experienced technicians to promptly address and resolve any hardware faults, providing timely assistance and solutions. We provide ongoing maintenance services to optimize performance, prevent disruptions, and address any evolving needs.
Tailored Solutions For The Pharmaceutical IndustryWecaps offers customization options to address the specific needs of your production processes. With 40 years of experience in the pharmaceutical sector, we can offer comprehensive turn-key solutions encompassing evaluation, design, installation, commissioning, and ongoing maintenance tailored specifically for the pharmaceutical industry. Opt for our comprehensive pharmaceutical solutions to bolster your success in the pharmaceutical industry.
